Black Steel Barn Door Hardware I-Shaped Rollers Track Rail
Upgrade your space with our Black Steel Barn Door Hardware Kit, designed for both aesthetic appeal and robust functionality. This kit is perfect for bypass barn doors, accommodating single or double doors with ease.
Product Specifications
Material: High-quality raw steel castings
Track Thickness: 6mm
Maximum Load: 330 pounds
Suitable Door Weight: 220 pounds
Suitable Door Panel Thickness: 4-4.5cm
Installation Requirements
The distance from the top of the hardware to the ceiling should be at least 16cm.
Baseboard thickness should be 2cm.
Door thickness should be between 4 and 4.5cm.
Ensure the wall can bear the weight of the hardware installation.
Orbit Calculation Method
Single Door: Track length = Door width x 2 + 10 cm
Track length = Opening x 2 + 20 cm
Double Doors: Track length = Door width x 4 + 20 cm
Track length = Door opening width x 2 + 20 cm
Installation Tools Required
Impact drill
Spirit level
Tape measure
Socket wrench
Hammer
Pencil
Screwdriver
Important Notes
This hardware kit includes only the necessary components for installation; door panels are not included. The track and wall connectors are pre-fixed on the track, and their positions are not adjustable. This hardware is designed for interior use only.
Please ensure the bottom of the door is prepared with an opening size of 20mm x 7mm before installation.
